    6 Tiers 204 Birds Broiler 45 Days Chicken Cage Battery Pullet

    Ask Lasest Price
    Brand Name : Silver star
    Model Number : H3L102/H4L136
    Certification : ISO9001,SGS
    Price : 108-135$/ set
    Payment Terms : T/T, Western Union
    Supply Ability : 2000 sets/week
    Delivery Time : 10-20 days
    • Product Details
    • Company Profile

    6 Tiers 204 Birds Broiler 45 Days Chicken Cage Battery Pullet

    45 Days Battery Pullet Broiler Chicken Cage​


    Automatic Feeding System of broiler chicken cage
    1.Main feed transport pipe connected with silo
    The material of the pipe: PPR pipe
    The diameter of the pipe: Ф90 mm
    2.Feeding trolley
    The material of the feeding trolley is hot dip galvanized steel to ensure no rust.
    3.Feeding trough
    Two kinds of raw materials for feeding trough are available: PVC or galvanized steel.

    Full automatic system of broiler chicken cage:

    1:H type battery pullet/broiler cage
    2:3tiers, 4tiers,5 tiers, 6tiers, 8tiers
    3:Q235 double hot galvanized anti-corrosion
    4:Q235 national standard double hot galvanized bridge steel cage,hot galvanized steel feed trough,ball type automatic water equipment ,white PVC pipe ,3MM U type galvanized steel shelves,closed-end pressure-reducer;Al-Zn material feeding system,AL-Zn material manure cleaning system,ventilation system,lighting system,environment controlling system and so on.


    Accessories of broiler chicken cage :
    1). The new white PVC material trough, compression, heat, deformation, not broken. Life span 15 years more. 100kg load-bearing.
    2). 3MM U-type galvanized steel frame leg: National standard 3MM thick steel plate, U shape design.
    350kg load-bearing. With double-DIP galvanizing, life span 15 years more.
    3). Automatic water nipple drinker: 360-degree rotating design, ball type or spring type. Stainless steel and plastic.
    4). White PVC water pipe: New PVC material, deformation, high temperature, difficult to damage. Impurities in the water will not produce a chemical reaction, thus ensuring the chickens can drink clean and healthy water. Useful life of 15 years more.
    5). Regulator: Fully enclosed design, voltage regulator and with filter.


    Broiler chicken cage specification :


    Tier
    Cell size
    Whole size
    Capacity/set
    Average area/bird
    3-tiers
    85*62.5*50 cm
    85*220*260 cm
    102 birds(1.5 kgs)
    312.5 cm2
    4-tiers
    85*62.5*50 cm
    85*220*325 cm
    136 birds(1.5 kgs)
    312.5 cm2
    5-tiers
    85*62.5*50 cm
    85*220*390 cm
    170 birds(1.5 kgs)
    312.5 cm2
    6-tiers
    85*62.5*50 cm
    85*220*455 cm
    204 birds(1.5 kgs)
    312.5 cm2
    8-tiers
    85*62.5*50 cm
    85*220*585 cm
    272 birds(1.5 kgs)
    312.5 cm2
