H Type Hot Galvanized Chick Brooder Cage 5 Tiers 170 Birds

Ask Lasest Price
Brand Name :	Silver star
Model Number :	H3L102/H4L136
Certification :	ISO9001,SGS
Price :	108-135$/ set
Payment Terms :	T/T, Western Union
Supply Ability :	2000 sets/week
Delivery Time :	10-20 days

Add to Cart

Product Details
Company Profile

H Type Hot Galvanized Chick Brooder Cage 5 Tiers 170 Birds

H Type Hot Galvanized Brooder Cage Broiler Chicken Cage

Free House Design For Broiler Chicken Cage:

We can provide professional free design according to the size of the house or the number of chickens

Drawing of H Type pullet/broiler Cages Introduction

H type 4 tiers pullet/broiler cage with full automatic system

Cage type : H type 4 tiers pullet/broiler cage
House size:99*13.5*4m
Cage size: 0.85*2.18*3.3m
136 chickens(1.5kgs)/set
107 sets/row
4 rows/house
Total: 4*107sets=428sets, 428*136 chikens/set=58208 chickens/house
Note: It is suggested that the maximum length and width of the house should not exceed 120 meters and 20 meters respectively

Why to choose cage raising chicken ?

1:The environment of chicken house is controllable, which is conducive to the physiological and production needs of chicken.
2: Automatic drinking, feeding, manure cleaning, eggs collecting, saving manpower, reducing raising cost, multi-layer cage saves more space than floor raising, high land utilization rate, saving chicken house construction and land cost.
3: Due to the good isolation between the close chicken house and the outside , the chance of cross contamination of chickens will be greatly reduced, which is conducive to the prevention and control of epidemic diseases, and save the cost of epidemic prevention.

Accessories of broiler chicken cage :
1). The new white PVC material trough, compression, heat, deformation, not broken. Life span 15 years more. 100kg load-bearing.
2). 3MM U-type galvanized steel frame leg: National standard 3MM thick steel plate, U shape design.
350kg load-bearing. With double-DIP galvanizing, life span 15 years more.
3). Automatic water nipple drinker: 360-degree rotating design, ball type or spring type. Stainless steel and plastic.
4). White PVC water pipe: New PVC material, deformation, high temperature, difficult to damage. Impurities in the water will not produce a chemical reaction, thus ensuring the chickens can drink clean and healthy water. Useful life of 15 years more.
5). Regulator: Fully enclosed design, voltage regulator and with filter.

Broiler chicken cage specification :

Tier	Cell size	Whole size	Capacity/set	Average area/bird
3-tiers	8562.550 cm	85220260 cm	102 birds(1.5 kgs)	312.5 cm2
4-tiers	8562.550 cm	85220325 cm	136 birds(1.5 kgs)	312.5 cm2
5-tiers	8562.550 cm	85220390 cm	170 birds(1.5 kgs)	312.5 cm2
6-tiers	8562.550 cm	85220455 cm	204 birds(1.5 kgs)	312.5 cm2
8-tiers	8562.550 cm	85220585 cm	272 birds(1.5 kgs)	312.5 cm2

H Type Hot Galvanized Chick Brooder Cage 5 Tiers 170 Birds
