    Automatic Poultry Feeding Broiler Equipment Chicken Floor Ground System 1.1KW

    Ask Lasest Price
    Brand Name : Silverstar
    Model Number : SSBR
    Certification : SGS, ISO9001, CE, SONCAP
    Price : $280-$360
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 100000 Set / Month
    Delivery Time : 15-30 days
    • Product Details
    • Company Profile

    Automatic Poultry Feeding Broiler Equipment Chicken Floor Ground System 1.1KW

    Automatic Poultry Feeding Equipments Chicken Broiler Floor Ground System


    Chicken house feeding system floor system broiler equipment for poultry farm is easy to assemble, much lower investment, achieves
    auto feeding, auto water drinking to save labor cost meanwhile.

    Followings are our broiler raising floor system chicken farms project plans:

    10000 Birds, 3 Feeding Lines, 4 Drinking Lines, House Size: 80x10x2.5m
    12000 Birds, 3 Feeding Lines, 4 Drinking Lines, House Size: 80x12x2.5m
    15000 Birds, 4 Feeding Lines, 5 Drinking Lines, House Size:75x16x2.5m
    15000 Birds, 3 Feeding Lines, 4 Drinking Lines, House Size: 100x12x2.5m
    20000 Birds, 4 Feeding Lines, 5 Drinking Lines, House Size: 100x15x2.5m
    25000 Birds, 6 Feeding Lines, 7 Drinking Lines, House Size: 95x20.5x2.5m
    30000 Birds, 4 Feeding Lines, 5 Drinking Lines, House Size: 150x16x2.5m


    Characteristics Of Chicken House Feeding System Broiler Equipment


    1. Vice HopperSize: 60Kg, 70Kg, 90Kg
    Material:hot-dip galvanized sheet, thickness:1mm
    2. Delivery Feed Pipe3m/set with 4holes pipe dia:45mm material:hot dip galvanized
    3. Feed Pan16 grid(4pan/3m) dia :360mm material:pure plastic material
    4. Feed Sensorimported from Germany
    time delay range: 0-2hours
    The sensor is usually installed at the end of each feeding line which controls motor on and off to achieve feed delivery automatically. The motor will start working and convey feed when sensor doesn't touch feed, the motor will stop conveying feed when sensor touchs feed.
    5. Driving motorTaiwan brand
    Power: 0.75Kw/1.1Kw/1.5Kw,
    Voltage:380V/220V/others, three-phase/single-phase
    Frequency:50Hz, AC current
    6. Nipple& Cupwith 360degree outer ABS plastic and inter stainless steel nipple,size: 3.4cm*1.0cm;
    single-arm drip cup with a reasonable structure is more suitable for new culture idea
    7. Water RegulatorDifferent volume of water can be delivered at an adjustable pressure.
    8. Medicator

    Dosatron

    injection rate:0.2%-2%

    Imported from France

    Operating pressure:0.3-6bar

    Operating flow: 10L/h to 2.5m3/h
    Concentrated additive injection: 0.02 to 50L/h

    9. PVC Square PipePVC material with European Technology, 4 or 5nipples/m;
    8-12chicken/nipple
    10. Galvanized Pipe
    galvanized steel with coating 275g/m2,diameter 25mm, thickness 1.2mm, 6m/pipe
